PROPULSION STANDARD
2x Black Mercury Verado V12 600 HP
FEATURES
• An exceptional performing and seaworthy double stepped hull shape providing first in class stability and fuel efficiency
• Expansive areas for entertaining and social zones from bow to stern with a well appointed wet bar area with refrigerator, sink, and storage.
• The bow seating offering comfortable seating for up to 4 people
• FUSION audio system with Bluetooth and 8 x Fusion Speakers and Multi Zone Sound Control
• Plenty of seating throughout for seating up 15 people onboard comfortably
• Expansive fiberglass hard top, designed for optional roof racks on hard top for SUP and Kayak with optional Makefast shade system for aft cockpit
• Console sliding door at helm area with direct access to interior cabin area which features a full sized king bed
• C-Zone digital switching system for DC powered components
• Structurally designed to accept optional side fold-out terraces
• Custom designed slide out stainless steel boarding ladder system providing easy access in and out of the water
CONSTRUCTION
• Vinylester resin infused throughout the hull and deck
• Vinylester resin infused throughout the bulkhead and reinforcing (no plywood in structural components or below waterline)
• Core materials (PVC) vary in density dependent on loads
• NPG gelcoat on hull • Water tight bulkheads fore and aft (NPG)
INTERIOR LAYOUT
• Cabin with king sized bed
• Wet head with fresh water electric flush toilet, sink with hot/cold faucet and shower
• Private lockable companionway door/stair to cabin
HULL FEATURES
• Double stepped hull design providing excellent performance and efficiency
• Aquila Protection Plan: 5 year hull/deck structural warranty
• NPG white gelcoat
• Vinylester resin infused hull, deck, cockpit floor and bulkheads
• Hull side black decal with opening portlight on starboard side
• Integrated transom walkthrough between engines with hidden slide out stainless steel ladder
• Large black rubrail around hull/deck joint providing maximum protection
FORWARD BOW SEATING
• Forward facing seating with flip down arm rests
• Designated storage areas for cell phones, sunscreen, and cup holders(4)
• Insulated storage with drains located under forward facing seating
• Recessed stainless steel handrails
• Central bow deck hatch providing access to windlass system
• Port and starboard bow wet locker storage for fenders and mooring lines
• Bow docking lights with LED strip and stainless steel cover
• Forward deck cockpit drainage
• Electric windlass with remote
• Bolster cushions installed on gunwale throughout boat with optional LED strip lighting
• Storage locker under floor in forward seating area with designated drainage
HELM CONSOLE
• Helm seating (4) with flip down bolster cushions, arm rests, and adjustable seat position • Cup holders at helm station (4)
• Upholstered glare reduction helm panel with designated storage areas above chart plotters • AC vents for direct air flow (aircon optional)
• LED strip lighting under helm dash
• Black acrylic helm panel for flush mounting chart plotters
• Integrated glove box with USB-A/C charging outlets
• Recessed foot rests
• Magnetic compass
• Windshield wiper system connected to fresh water supply with control at helm
• Ergonomically positioned throttle and joystick controls
• Fusion Apollo Series MS-RA770 marine stereo head unit
• C-Zone 5” Display for controlling DC electrical items
• Variable position stainless steel steering wheel with spinner knob
• Stainless steel handrails (2)
• Composite fiberglass and stainless steel supports for windshield
• Manual push button override switches and controls
GALLEY BLOCK
• Cup holders (4)
• Garbage bin receptacle on each side (2)
• Stainless steel hand rail
• Tackle box storage on back side of galley block (2) - optional cooler or fridge space
• Sink with faucet and cutting tray
• Corian countertop for serving beverages and food
• Designated location for optional two burner BBQ or induction cooktop
• Acrylic back splash panel
• Location for optional TV lift system
• Electrical outlet (AC)
AFT DECK & COCPIT
• Self draining cockpit area
• Mechanical room access from deck hatches (2)
• Stainless steel walkthrough gates with acrylic panels on each side of seating (2)
• Patented Aquila slide out concealed stainless steel swim ladder with integrated hand holds
• Fresh water pull out shower (hot/cold)
• Ten cup holders (10)
• Manual hi/low table at forward and aft facing seating areas with fill in cushion to convert to bed or sun lounger (2)
• Fiberglass table at forward and aft U-shaped seating area (2)
• Manual sliding adjustable backrest
• U-shaped convertible seating for facing aft or forward
• Storage areas under seating accessible through hinged cushions
• Stainless steel railings on each side of central walkthrough area where slide out swim ladder is located
• Optional aft deck flip down hydraulic platforms on each side of hull with push button controls
• Lighting - LED strip under seat
HARD TOP
• Expansive fiberglass hardtop with dedicated positions for nav equipment and optional roof racks
• Stainless steel handrails on forward port and starboard side of hard top
• Black painted main support pillars with integrated stainless steel handrail
• Underside of hard top in white gelcoat with option available to have painted in black
• Marine waterproof speakers 7.7” (4)
• Optional electrical slide out canvas shade system from aft section of hard top providing shade to aft deck seating
• Lighting - Two (2) flush mounted LED spreader lights on aft section of hard top (2 total) • Lighting - LED overhead lighting (color changing)
• LED navigation lights - port, starboard, anchor & running light
DECK FEATURES
• Bolster cushions installed throughout boat
• Marine waterproof speakers 7.7” mounted on gunwale(4)
• Ten (10) x 10” pop up cleats: Stern (2), Spring (4), Bow (4)
• Track system step design providing dual purpose entrance into cabin with above deck access to forward cockpit
• Integrated deck level 316 stainless steel hand rail
• Lighting - LED courtesy lighting • Easy access on and off boat from aft side decks
• Recessed hidden storage in gunwales for mooring lines and fenders
• Fixed aft gunwale which can be upgraded to the GHS hydraulic fold down side doors (2)
• Molded recessed deck hatches with gaskets and stainless steel latches providing access to below deck areas (8)
• Deck fill plates in 316 stainless steel - 1 x water - 2 x fuel - 1 x waste
• Self draining deck design • Engine well fiberglass hinged hatches for maximizing space on aft deck (2)
• Hatches to access mechanical aft deck space (2)
MOORING SYSTEMS
• Electric windlass (12v-1500W) with hard wired handheld control at anchor locker
• Anchor platform and roller in 316 stainless steel
CABIN
• Main electrical switch panel for common use electrical components
• Direct access via lockable companionway door into cabin area from main deck
• Cabinetry in composite laminate and matching hard wood trim
• Synthetic wear resistant flooring offering maintenance free natural look
• Upholstered side and ceiling panels
• Blinds for starboard side and overhead windows
• Lightning - LED accent strip lighting, overhead lights, and reading lights
• Opening portlight on starboard side
• Carbon monoxide/smoke detector
• Large acrylic skylight providing maximum light in cabin
• AC power outlets
• Storage shelves, lockers and drawers
• Memory foam mattress size: 80” x 78” (203cm x 197cm)
• Stainless steel hand rail for ease of access in and out of bed
• Additional storage under bed • Corian countertops and accent areas
HEAD
• Corian basin surface
• Vanity with sink, polished chrome faucet with hot/cold water
• Pull out shower wand with hot/cold mixer controls
• Electric fresh water flush toilet, holding tank, overboard discharge, dockside pump-out and tank level indicator
• AC power receptacle (GFCI protected)
• Mirror with light • Toilet paper holder
• Toothbrush and towel holders • Wet head shower acrylic door to keep water within head area
• Teak grate in shower area
• Hinged bench seat over toilet
• Storage lockers with trash bin behind the toilet
• Storage under sink
• Stainless steel handrail next to toilet
• LED lighting in ceiling
ELECTRICAL
• C-Zone digital switching system with 5” display at helm
• LED navigation and anchor lights
• Fusion Signature Series audio package - 770 control head, 8 x 7.7” speakers
• Master control panel for 12vDC and AC shore power service
• Remote battery switches
• House battery bank with charging system - 4 x 200Ah AGM • Optional lithium battery package for off grid use of aircon system
• Shore side power electrical system connection with galvanic isolator
• Inverter/battery charger(s)- 12V/3500W
• Electric horn
• Each hull with automatic bilge pump with ability to manually operate at helm
• Engine starter batteries (2 x 105 A/h) AGM technology
• LED lighting throughout
• Helm station LED lit manual push button panel
• Engine parallel control remote switch
WATER, WASTE & BILGE SYSTEMS
• Fresh water tank (50 Gal / 189 L)
• Black water holding tank (21Gal / 80L), overboard discharge with valve, dockside pump-out and tank level indicator
• Automatic 12v fresh water pump
• Water heater (1 x 10.5Gal / 40 L)
• Faucet - inside head area - hot/cold
• Head Shower - hot/cold
• Aft cockpit pull out shower - hot/cold
• Four (4) automatic 12v bilge pumps
• Automatic grey water pump connected to each shower drain for direct overboard discharge
• Windshield wiper water supply connected to main fresh water supply
• Black and fresh water levels visible through C-Zone system
SPECIFICATIONS
LENGTH Overall: 14.17 M • 46’ 6”.
BEAM: 4.57 M • 15’ 0”
BEAM: 5.88 M • 19’ 4” WITH FOLD-OUT TERRACES OPEN.
HEIGHT: 3.02 M • 9’11” ABOVE WATERLINE WITH HARDTOP (EXCLUDING ELECTRONICS)
DRAFT: 1.04 M • 3’ 5” WITH OUTBOARD ENGINES DOWN.
LIGHT DISPLACEMENT: 9,965 KG • 21,969 LB
LOADED DISPLACEMENT: 14,279 KG • 31,480 LB
ACCOMMODATIONS
SLEEPS UP TO: 2
MAXIMUM PASSENGERS: 29
CABINS: 1
HEADS WITH SHOWERS: 1
TANKAGE
FUEL: 1,514 L • 400 GAL
WATER: 189 L • 50 GAL
HOLDING: 80 L• 21 GAL
CE CERTIFICATION
B (OFFSHORE): 10
C (COASTAL): 20
D (INLAND): 29
