PROPULSION
STANDARD
2x Mercury Verado V8 300 HP WITH ELECTRO HYDRAULIC STEERING
OPTIONAL
2x Mercury Verado V10 400 HP WITH JPO / ELECTRIC STEERING
FEATURES
• An exceptional performing and seaworthy double stepped hull shape providing first in class stability and fuel efficiency
• Expansive areas for entertaining and social zones from bow to stern with a well appointed wet bar area with sink, and storage.
• The bow seating offering comfortable seating for up to 4 people
• FUSION audio system with Bluetooth and 6 x Fusion Speakers and Multi Zone Sound Control
• Plenty of seating throughout for seating up 13 people onboard comfortably
• Expansive fiberglass hard top, designed for optional roof racks on hard top for SUP and kayak with optional Makefast shade system for aft cockpit
• Console sliding door at helm area with direct access to interior cabin area which features a full sized queen bed
• C-Zone digital switching system for DC powered components
• Custom designed slide out stainless steel boarding ladder system providing easy access in and out of the water
HULL
• Double stepped hull design providing excellent performance and efficiency
• Aquila Protection Plan: 6 year hull/deck structural warranty
• NPG white gelcoat
• Vinylester resin infused hull, deck and bulkheads
• Hull side black decal with opening portlight on starboard side
• Integrated transom walkthrough between engines with hidden slide out stainless steel ladder
• Large black rubrail around hull/deck joint providing maximum protection
FORWARD BOW SEATING
• Forward facing seating with flip down arm rests
• Cup holders (4)
• Insulated storage with drains located under forward facing seating
• Recessed stainless steel handrails
• Central bow deck hatch providing access to optional windlass system with remote
• Port and starboard bow wet locker storage for fenders and mooring lines
• Bow docking lights with LED strip and stainless steel cover
• Forward deck cockpit drainage
• Bolster cushions installed on gunwale throughout boat with optional LED strip lighting
• Easy access starboard side steps
• Marine waterproof speakers 7.7” (2)
HELM CONSOLE
• Helm seating (4) with flip down bolster cushions, arm rests, and adjustable seat position • Cup holders at helm station (4)
• Upholstered glare reduction helm panel with designated storage areas above chart plotters • Black acrylic helm panel for flush mounting chart plotters
• Integrated glove box with USB-A/C charging outlets
• Recessed foot rests
• Ergonomically positioned throttle
• Fusion Apollo Series MS-RA670 marine stereo head unit
• C-Zone 5” Display for controlling DC electrical items
• Variable position steering wheel
• Stainless steel handrails (2)
• Composite fiberglass and stainless steel supports for windshield
• Manual push button override switches and controls
• Magnetic handheld compass
GALLEY BLOCK
• Cup holders (4)
• Garbage bin receptacle (1)
• Stainless steel hand rail
• Pull out drawer storage under the port side helm seat (1)
• Electrical AC breaker switches located under helm seating
• Galley equipment storage on aft side of galley block
• Sink with faucet and cutting tray
• Corian countertop for serving beverages and food
• Designated location for optional single burner BBQ or induction cooktop
• Acrylic back splash panel
AFT DECK & COCKPIT
• Electric windlass (12v-1000W) with hard wired handheld Self draining cockpit area
• Mechanical room access from deck hatches (2)
• Stainless steel walkthrough gates with acrylic panels on each side of seating (2)
• Patented Aquila slide out concealed stainless steel swim ladder with integrated hand holds
• Fresh water pull out shower
• Cup holders (5)
• Manual sliding forward and aft adjustable backrest
• U-shaped convertible seating for facing aft or forward
• Storage areas under seating accessible through hinged cushions
• Stainless steel railings on each side of central walkthrough area where slide out swim ladder is located
• Electronic control sliding U shape seating module - allows ability to slide seating to port or stbd side for access into deck hatches
HARD TOP
• Expansive fiberglass hardtop with dedicated positions for nav equipment and optional roof racks
• Stainless steel handrails on forward port and starboard side of hard top
• Black painted main support pillars with integrated stainless steel handrail
• Lighting - Two (2) flush mounted LED spreader lights on aft section of hard top (2 total) • Lighting - LED overhead lighting (color changing)
• LED navigation lights - port, starboard, anchor & running light
DECK FEATURES
• Bolster cushions installed throughout boat
• Marine waterproof speakers 7.7” mounted on gunwale(4)
• Ten (12) x 10” pop up cleats: Stern, Spring, Bow (4 each)
• Track system step design providing dual purpose entrance into cabin with above deck access to forward cockpit
• Integrated deck level 316 stainless steel hand rail
• Easy access on and off boat from aft side decks
• Molded recessed deck hatches with gaskets and stainless steel latches providing access to below deck areas (6)
• Deck fill plates in 316 stainless steel - 1 x water - 2 x fuel - 1 x waste
• Self draining deck design • Engine well fiberglass hinged hatches for maximizing space on aft deck (2)
• Hatches to access mechanical aft deck space (2)
CABIN
• Main electrical switch panel for common use electrical components
• Direct access via lockable companionway door into cabin area from main deck
• Composite laminate carpentry and matching wood trim
• Synthetic wear resistant flooring offering maintenance free natural look
• Upholstered side and ceiling panels
• Blinds for port side and starboard side and overhead windows
• Lightning - LED accent strip lighting, overhead lights, and reading lights
• Opening portlight on port and starboard side • Carbon monoxide/smoke detector
• Large acrylic skylight providing maximum light in cabin
• Storage shelves, lockers and drawers
• Memory foam mattress size: 78” x 74” (199cm x 187cm)
• Stainless steel hand rail for ease of access in and out of bed
• Additional storage under bed • Corian countertops and accent areas
HEAD
• Corian basin surface
• Vanity with polished chrome faucet with hot/cold water
• Pull out shower wand with hot/cold mixer controls
• Electric fresh water flush toilet, holding tank, overboard discharge, dockside pump-out and tank level indicator
• Mirror with light
• Toilet paper holder
• Toothbrush and towel holders Wet head shower acrylic door
• Teak grate in shower area • Hinged bench seat over toilet
• Storage lockers with trash bin behind the toilet
• Storage under sink
• Stainless steel handrail next to toilet
• LED lighting in ceiling
ELECTRICAL
• C-Zone digital switching system with 5” display at helm
• LED navigation and anchor lights
• Fusion Signature Series audio package - 670 control head, 6 x 7.7” speakers
• Master control panel for 12vDC
• Remote battery switches
• House battery bank w/charging system - 2 x 200Ah AGM
• Optional lithium battery package for off grid use of aircon system
• Electric horn
• Each hull with automatic bilge pumps with ability to manually operate at helm • Engine starter batteries - AGM technology
• LED lighting throughout
• Helm station LED lit manual push button panel
• Engine parallel control remote switch
• Shore side power electrical system connection with galvanic isolator
FUEL SYSTEM
• Fully independent heavy gauge aluminum tanks (2) totaling 396 US G (1,500 L)
• Manual fuel shut off valves
• Mercury engine fuel/water separators
• EPA regulated fuel breather/filler system
WATER AND BILGE SYSTEM
• Automatic 12v Fresh Water Pump
• Water heater (1) @ 40L/10.5Gal (only operable from shore power and/or optional generator) • 1 x 200 Liter/52 US G fresh water tank • Transom pull out shower mixer (hot/cold)
• Automatic 12v bilge pumps (6)
WATER / WASTE / BILGE
• Fresh water tank (50 Gal / 189 L)
• Black water holding tank (21Gal / 80L), overboard discharge with valve, dockside pump-out and tank level indicator
• Automatic 12v fresh water pump
• Faucet - inside head area
• Head shower • Aft cockpit pull out shower
• Six (6) automatic 12v bilge pumps
• Automatic grey water pump connected to each shower drain for direct overboard discharge
• Black and fresh water levels visible through C-Zone system
SPECIFICATIONS
LENGTH OVERALL: 10.81 M • 35’ 6”
BEAM:4.49 M • 14’ 9”
HEIGHT: 3.09 M • 10’ 2” ABOVE WATERLINE WITH HARDTOP (EXCLUDING ELECTRONICS)
DRAFT: 0.79 M • 1’ 8” WITH OUTBOARD ENGINES DOWN
LOADED DISPLACEMENT: 9,053 KG • 19,985 LB
ACCOMMODATIONS
SLEEPS: 2
MAX PASS: 24
CABINS: 1
HEADS W/SHOWERS: 1
TANKAGE
FUEL: 1,500 L • 396 GAL
WATER: 189 L • 50 GAL
HOLDING: 80 L• 21 GAL
CE CERTIFICATION
B (OFFSHORE): 8
C (COASTAL): 16
D (INLAND): 24
